Chipanalog CA-IF1021D-Q1 Interface IC

Chipanalog CA-IF1021D-Q1

The CA-IF1021x-Q1 family of device is Local Interconnect Network (LIN) transceiver with integrated wake-up and protection features for automotive applications. LIN is low speed universal asynchronous receiver transmitter (UART) communication protocol used to support in-vehicle networks. The CA-IF1021x-Q1 transceiver controls the LIN bus state via the TXD input and reports the bus state on its open-drain output RXD between the protocol controller and physical LIN networks. These device features slew-rate control and wave-shaping to reach a very low level of electromagnetic emission (EME) within a broad frequency range.

Features

• Meets LIN2.0、LIN2.1、LIN2.2、LIN2.2A and ISO 17987-4:2016(12V) Physical-layer (EPL) Standards
• Compliant to SAE J2602-1 and SAE J2602-2 LIN Physical-layer Specification
• Designed to Support 12V Applications with Wide Operating Supply Range
• 5.5V to 27V supply range (VBAT)
• 3.3V and 5.0V Input Logic Compatible
• System-level Power Control via INH pin
• Power-up/down Glitch-free Operation on LIN bus and RXD output
• Integrated 30kΩ LIN pull-up Resistor
• Support up to 20kbps LIN Transmission Data Rate
• Operating Mode
• Normal operation
• Low-power sleep
• Low-power standby
• Power-on
• Wake-up from Low-power Mode
• Remote wake-up via LIN bus
• Local wake-up via WAKE_N or SLP_N pins
• Integrated Protection Increases Robustness
• ±58V fault-tolerant LIN bus
• 42V load dump protection

Applications

• Body electronics
• Automotive gateway
• Infotainment and cluster
• Hybrid electric vehicles and powertrain systems

Device Information
