Chipanalog CA-IF43232EN Interface IC
Share
pCA-IF43232EN — Interface IC by Chipanalog (Chip Analog Microelectronics). Meets or Exceeds the Requirements of the TIA/ EIA-232-F and ITU V.28 Standards/p
- Product Details
- Download
Chipanalog CA-IF43232EN
Features
- Meets or Exceeds the Requirements of the TIA/ EIA-232-F and ITU V.28 Standards
- Bus Pins (RINx and DOUTx) ESD Protection
- ±15kV HBM ESD
- ±8kV IEC 61000-4-2 Contact Discharge
- ±15kV IEC 61000-4-2 Air-gap Discharge
- Operates With 3-V to 5.5-V VCC Supply
- Two Drivers and Two Receivers
- Maximum Data Rate
- 250kbps
- Low Supply Current
- 1mA (typical)
- Two Charge Pumps With External Capacitors
- 4 × 0.1μF (VCC = 3.3V)
- Accepts 5-V Logic Input With 3.3-V Supply
- Extended Industrial Temperature Range: –40°C to 125°C
Applications
- Wired Networking
- Data center and Enterprise Computing
- Battery-Powered Systems
- Computer
- Printer
Device Information
| Package size(NOM) |
| CA-IF43232EN |
| SOIC16-NB(N) |
| 10.0mm*3.9mm |
| CA-IF43232ETB |
| TSSOP16 (TB) |
| 5mm × 4.4mm |
| CA-IF43232EX_V1.1 |
| CA-IF43232EN_V1.0 |
