Chipanalog CA-IS1200G Isolated Sensing IC

Chipanalog CA-IS1200G

Features

• Differential Input Voltage Range
• ±250 mV
• Fixed Initial Gain
• 8
• Low Input Offset and Drift
• ±1 mV (max) at 25°C, ±4 μV/°C (max)
• Low Gain Error and Drift
• ±0.5% (max) at 25°C, ±50 ppm/°C (max)
• Low Nonlinearity and Drift
• 0.01% (typ) for Full Scale, ±1 ppm/°C (typ)
• 3.3-V or 5-V Operation for Both High- and Low-Side
• High CMTI
• ±150 kV/µs (typ)
• Wide Operating Temperature Range
• –40°C to 125°C
• Safety-Related Certifications
• 7070-V
• PK
• (CA-IS1200G) Isolation per DIN EN IEC 60747-17 (VDE 0884-17)
• 5000-V

Applications

• Industrial Motor Controls and Drives
• Isolated Switch Mode Supplies
• Uninterruptible Power Supplies

Device Information
