Chipanalog CA-IS23050S Sensor IC

Chipanalog CA-IS23050S

The CA-IS23xxxS family is a series of highly accurate and cost-effective current sensor IC suitable for AC/DC current sensing in a variety of industrial, commercial, and communications systems. It features a low-offset, linear Hall sensor circuit and a copper conduction path that generates a magnetic field when current flows through it. The integrated Hall IC senses this magnetic field and converts it into a proportional voltage output, which has a positive slope proportional to the current flowing through the primary copper conduction path. The device senses current differentially, rejecting common-mode fields and improving accuracy in magnetically noisy environments. With its 1mΩ internal resistance, the primary copper conduction path offers low power loss and high inrush current withstand capability.

Features

• Differential hall sensing rejects common-mode fields and nearly zero magnetic hysteresis
• Integrated digital temperature compensation circuitry allows for near closed loop accuracy
• High immunity to external magnetic fields
• Precision zero-current reference output
• Primary conductor resistance
• 1mΩ
• High current sense range capability
• CA-IS23025S: ±25APK
• CA-IS23030S: ±30APK
• CA-IS23050S: ±50APK
• Fast response
• Signal bandwidth: 120kHz
• Propagation delay: 2µs
• Response time: 3.7µs
• Operating supply voltage
• 4.5V to 5.5V
• Bidirectional and unidirectional current sensing
• -40°C to +150°C Operating Junction Temperature Range
• Robust Galvanic Isolation
• 3750VRMS withstand isolation voltage

Applications

• Solar Energy
• Motor Control
• EC Charging
• Power Supplies
• Industrial AC/DC and DC/DC

Device Information
