Chipanalog CA-IS3020WG Isolated Interface IC
Share
pThe CA-IS302x devices are complete dual-channel, galvanic digital isolators with up to 3.75kV/p
- Product Details
- Download
Chipanalog CA-IS3020WG
The CA-IS302x devices are complete dual-channel, galvanic digital isolators with up to 3.75kV
Features
- Bidirectional Data Transfer from DC to 2MHz
- Robust Galvanic Isolation of Digital Signals
- High lifetime: > 40 years
- Withstands up to 3.75kV
- RMS
- (narrow-body package), 5kV
- RMS
- (wide-body packages) and 7.5kV
- RMS
- (super wide-body packages) isolation rating for 60s (V
- ISO
- )
- ±150 kV/μs typical CMTI
- Schmitt trigger inputs for high noise immunity
- High electromagnetic immunity and withstands ±12.8kV surge voltage
- ±8kV Human Body Model ESD Protection
- 3.0V to 5.5V Wide Supply Operation
- Wide Operating Temperature Range
- -40°C to 125°C
- RoHS-Compliant Packages
Applications
- I
- 2
- C, SMBus, PMBus™ Interfaces
- Motor control systems
- Medical Equipment
- Battery Management
- Instrumentation
Device Information
| BODY SIZE (NOM) |
| CA-IS3020 |
| CA-IS3021 |
| SOIC8(S) |
| 4.90mm×3.90mm |
| SOIC8-WB(G) |
| 5.85mm×7.50mm |
| SOIC16-WB(W) |
| 10.30mm×7.50mm |
| CA-IS3020 |
| SOIC8-WWB(WG) |
| 6.40mm × 14.00mm |
