Chipanalog CA-IS3082WX Isolated Interface IC

Chipanalog CA-IS3082WX

The CA-IS308x family of devices is a galvanically-isolated RS485/RS-422 transceiver that has superior isolation and

Features

• High-Performance and Compliant with RS-485 EIA/TIA-485 Standard
• 500kbps, 10Mbps or 20Mbps data rate optional
• 1/8 unit load enables up to 256 nodes on the bus
• 2.375V to 5.5V logic side supply voltage and 3 V to 5.5 V bus side supply voltage
• Bus common mode supply rage
• CA-IS3080/86: -15V to +15V
• CA-IS3082/88: -7V to +12V
• CMTI
• ±150kV/μs (typical)
• Output current limited and thermal shutdown protection on driver side
• Open、short circuit protection and bus failure protection
• Wide operating temperature range
• –40°C to 125°C
• Wide-body SOIC16-WB(W) Package
• High lifetime
• >40 years

Applications

• Industrial Automation Equipment
• Grid infrastructure
• Solar inverter
• Motor drivers
• HVAC

Device Information

Download Datasheet (PDF)
