Chipanalog CA-IS3211VCJ Isolated Gate Driver

Chipanalog CA-IS3211VCJ

The CA-IS3211 devices are a family of single-channel, optocompatible isolated gate driver capable of sinking 6A andsourcing 5A currents. These devices operate with dualsupplies or a single supply of 10V to 30V (8V UVLO version)or 14V to 30V (12V UVLO) wide voltage range of VCC - VEE,making them ideal to drive power MOSFET, IGBT or siliconcarbide(SiC) transistors in various inverter, motor control orisolated power supply systems. The CA-IS3211 can beconfigured as low-side and high-side drivers. The CAIS3211V_ offers single terminal gate drive output: VOUT andthe CA-IS3211S_ offers dual separate output terminals:OUTH and OUTL. The driver output is pulled to low state toturn-off external power transistors when V

Features

• 6A Peak Sink Current and 5A Peak Source Current
• Up to 30V Output Drive Supply Range with 8V (CAIS3211VB_) and 12V (CA-IS3211VC_) UVLO options
• Support Rail to Rail Output
• Up to 7V Reverse Voltage on Input-stage
• Matching Propagation Delay
• 70ns Propagation delay (typical)
• 25ns Part to part propagation delay matching (maximum)
• 35ns Pulse width distortion(maximum)
• -40°C to +150°C Operating Junction Temperature Range
• Robust Galvanic Isolation
• High lifetime: >40 years
• Up to 5.7kV
• RMS
• isolation rating for the wide-body packages and up to 3.75 kV
• RMS
• isolation rating for CA-IS3211VCU
• Common-mode transient immunity (CMTI) >±150kV/μs
• Package options
• 6-pin wide-body SOIC (J) Package
• 8-pin wide-body SOIC8 (G) Package

Applications

• Isolated DC-DC and AC-DC Converters
• Motor Contro
• Uninterruptible Power Supply (UPS)
• Isolated Gate Driver for Inverters

Device Information
