KDS DSX530GK Crystal Resonator 7-8MHz 5.0x3.2x1.0mm
Share
KDS DSX530GK — Crystal Resonator, 7-8MHz, 5.0x3.2x1.0mm SMD. Excellent heat resistance, High reliability. AEC-Q200 Compliant.
- Product Details
- Download
KDS DSX530GK Crystal Resonator
SMD Crystal Resonators / MHz Band Crystal Resonators〈For Automotive〉 — Crystal Resonator, 7-8MHz, 5.0x3.2x1.0 mm.
Features
- Miniature and low profile SMD crystal resonator (height 1.0mm)
- Excellent heat resistance, High reliability.
- AEC-Q200 Compliant
Applications
- Multimedia devices such as car navigation systems and car audio
Standard Specification
| Type | DSX530GA |
| Item | |
|---|---|
| Frequency Range | 7 to 8MHz |
| Overtone Order | Fundamental |
| Load Capacitance | 8pF, 10pF, 12pF |
| Drive Level | 10μW （300μW max.） |
| Frequency Tolerance | ±30×10 -6 ( at 25℃) |
| Series Resistance | 200Ω max. |
| Frequency Characteristics over | |
| Temperature | |
| Storage Temperature Range | −40 to ＋150℃ |
| Reliability | AEC-Q200 |
| Packing Unit (1) | 1000pcs./reel (φ180） |
| Moisture Sensitivity Level：LEVEL1 (IPC/JEDEC J-STD-033） | |
