Meanwell LRS-150F-36 Enclosed Switching Power Supply 36V 4.3A 150W
Share
pMeanwell LRS-150F-36: 36V, 0~4.3A, 150W. Universal AC input, efficiency 89.0%, ripple 200mV./p
- Product Details
- Download
Meanwell LRS-150F-36
Enclosed type switching power supply, 36V / 0~4.3A (150W), universal AC input 85~264VAC, efficiency 89.0%.
Specifications
| Model | LRS-150F-36 |
| Output Voltage | 36V |
| Output Current | 0~4.3A |
| Rated Power | 150W |
| Voltage Tolerance | ±1% |
| Ripple & Noise | 200mV |
| Efficiency | 89.0% |
| AC input voltage range | 85~264VAC; 120~370VDC 115 / 230VAC by switch |
| AC inrush current | (max.) Cold start, 60A at 230VAC |
| DC adjustment range | ±10% by potentiometer |
| Overload | Range 110%~140% |
| Withstand voltage | I/P-O/P: 4kVAC, I/P-FG: 2kVAC, O/P-FG: 1.25kVAC I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC |
| Working temperature | -30~+70°C (refer to output derating curve) -25~+70°C (refer to output derating curve) |
| Dimension | (LxWxH) (mm) 159x 97x 30 215x 115x 30 |
