Meanwell LRS-350-36 Enclosed Switching Power Supply 36V 9.7A 350W
Share
pMeanwell LRS-350-36: 36V, 0~9.7A, 350W. Universal AC input, efficiency 88.5%, ripple 200mV./p
- Product Details
- Download
Meanwell LRS-350-36
Enclosed type switching power supply, 36V / 0~9.7A (350W), universal AC input 85~264VAC, efficiency 88.5%.
Specifications
| Model | LRS-350-36 |
| Output Voltage | 36V |
| Output Current | 0~9.7A |
| Rated Power | 350W |
| Voltage Tolerance | ±1% |
| Ripple & Noise | 200mV |
| Efficiency | 88.5% |
| AC input voltage range | 85~264VAC; 120~370VDC 115 / 230VAC by switch |
| AC inrush current | (max.) Cold start, 60A at 230VAC |
| DC adjustment range | ±10% by potentiometer |
| Overload | Range 110%~140% |
| Withstand voltage | I/P-O/P: 4kVAC, I/P-FG: 2kVAC, O/P-FG: 1.25kVAC I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC |
| Working temperature | -30~+70°C (refer to output derating curve) -25~+70°C (refer to output derating curve) |
| Dimension | (LxWxH) (mm) 159x 97x 30 215x 115x 30 |
