Modified Single-Layer USB 2.0 90 Degree Connector - C040080
Modified Single-Layer USB 2.0 90 Degree Connector - C040080

Modified Single-Layer USB 2.0 90 Degree Connector - C040080

Share
pDouble-to-single layer conversion with raised base. 30V DC, 100V dielectric strength./p
  • Rated current: 1.5A
  • Rated voltage: 30V DC
  • Contact impedance: 30m Ohm
  • Insulation impedance: 100m Ohm
  • Withstand voltage: 100V
  • Operating temperature: -55 Degree C~+85 Degree C
  • Rubber core: high temperature material, UL94-V0
  • Terminal: PHOSPHOR BRONZE, half gold tin plated
  • Casing: SUS, nickel plated
[email protected]
Previous
USB 2.0 Triple-Layer 90 Degree Angled-Pin Connector - C023680
usb connector typesfemale connector usbUSB A connectorusb charger typesusb a to a connector
  • Product Details
  • Download

Space-saving design with nickel-plated brass shell. -55 Degree C to 85 Degree C operating range.
