Side-Mount USB 2.0 90 Degree Bent-Pin Connector - C071171
Side-Mount USB 2.0 90 Degree Bent-Pin Connector - C071171

Side-Mount USB 2.0 90 Degree Bent-Pin Connector - C071171

Share
pLong-body side-mount with bent pins. 30V DC, UL94-V0 housing./p
  • Rated current: 1.5A
  • Rated voltage: 30V DC
  • Contact impedance: 30m Ohm
  • Insulation impedance: 100m Ohm
  • Withstand voltage: 100V
  • Operating temperature: -55 Degree C~+85 Degree C
  • Rubber core: high temperature material, UL94-V0
  • Terminal: PHOSPHOR BRONZE, half gold tin plated
  • Casing: SUS, nickel plated
[email protected]
Previous
4-Port USB 3.0 Type-A Connector - C071070
usb connector typesUSB A connectorusb charger typesusb a to a connector
  • Product Details
  • Download

Right-angle connector for edge PCB mounting. Phosphor bronze contacts with tin plating.
