SII SSP-T7-F Crystal Resonator 32.768kHz 7.0x1.5x1.4mm
Share
pSII SSP-T7-F — Crystal Resonator, 32.768kHz, 7.0x1.5x1.4mm. Small plastic molded type (7.0 x 1.5 x 1.4 mm)./p
- Product Details
- Download
SII SSP-T7-F Crystal Resonator
SSP-T7-F — Crystal Resonator, 32.768kHz, 7.0x1.5x1.4mm.
Features
- Small plastic molded type (7.0 x 1.5 x 1.4 mm)
- SMD type suitable for automatic & high density surface mounting.
- Excellent shock and heat resistance.
- Complies with EU RoHS directive
- Halogen free
- A crystal resonator processed by high reliable photolithographic technology inside.
Standard Specification
| Item | Symbol | Specifications |
|---|---|---|
| Nominal Frequency | f_nom | 32.768kHz |
| Frequency Tolerance | f_tol | ±5 x 10-6、±10 x 10-6、±20 x 10-6 ※Please contact us for inquiries regarding available tolerance. |
| Turnover Temperature | Ti | +25±5ºC |
| Parabolic Coefficient | B | (−0.033±10%) x 10-6/ºC2 |
| Load Capacitance | CL | 7.0pF、9.0pF、12.5pF ※Please contact us for inquiries regarding available CL. |
| Motional Resistance(ESR) | R1 | 65kΩ max. |
| Absolute Maximum Drive Level | DLmax. | 1.0μW max. |
| Drive Level | DL | 0.1μW |
| Shunt Capacitance | C 0 | 0.9pF typ. |
| Frequency Ageing | f_age | ±3 x 10-6 |
| Operating Temperature | T_use | −40ºC to +85ºC |
| Storage Temperature | T_stg | −55ºC to +125ºC |
