SII VT-200-FL Crystal Resonator
32kHz Crystal Resonator for Low-Power.
Features
- Consumes one tenth the standby power of general crystal resonators (with a load capacitance of 12.5 pF)
- Photo-lithograhic process.
- Excellent low drive level characteristics.
- Pb-free.
- Complies with EU RoHS directive
Standard Specification
| Item | Symbol | Specifications |
|---|---|---|
| Nominal Frequency | f_nom | 32.768kHz |
| Frequency Tolerance | f_tol | ±5 x 10-6、±10 x 10-6、±20 x 10-6 ※Please contact us for inquiries regarding available tolerance. |
| Turnover Temperature | Ti | +25±5ºC |
| Parabolic Coefficient | B | (−0.035±10%) x 10-6/ºC2 |
| Load Capacitance | CL | 3.7pF、4.4pF、6.0pF ※Please contact us for inquiries regarding available CL. |
| Motional Resistance(ESR) | R1 | 50kΩ max. |
| Absolute Maximum Drive Level | DLmax. | 1.0μW max. |
| Drive Level | DL | 0.01μW |
| Shunt Capacitance | C 0 | 0.9pF typ. |
| Frequency Ageing | f_age | ±3 x 10-6 |
| Operating Temperature | T_use | −40ºC to +85ºC |
| Storage Temperature | T_stg | −40ºC to +85ºC |
